63
Here " Block", "Single" and "2 CHA" can be selected.
- SINGLE : means that the DMX address of each channel is selectable,
and even that the 12 channels can select the same DMX
addresses.
- Block : means that the complete dimmer(12 channels) has only one
start address.
-2 CHA :
means that the 2-channel switch-mode is active. This mode is
necessary, if only 2 single DMX channels control all 12 dimmer
channels.
Mode of operation:
64 different combinations for the first DMX channel control
channels No.1~6; The 2nd DMX channel controls the dimmer
channels 7~12.
2.4.3 DMX MIDI
Here the digital serial input can be selected : DMX-512 or MIDI.
MIDI only accepts " program change" commands . Other commands are
neglected. MIDI is intended for controlling and calling up 12 internal
MEMORIES, CHASE or OFF. In MIDI status, the external analogue
commands will be activated.
MDP-1219 Instructions page 21
63
A total of channels 1~16 can be selected.
2.4.5 Phase Correction
2.4.6 USER MODE
With this function the dimmer function can be cut down in 3 steps.
-SUPER : "Supervisor" means that all functions can be used.
-NORM : "Normal User" means that in the Channel Menu, only the
DMX address can be programmed. The Memory Menu is
switched off. After having tested the dimmer functions,
the user shall use this mode, which helps protect the
parameters set by the dimmer. The DMX address shall be
programmable.
- LOCK : The dimmer is completely locked and can be not be
operated with the buttons or encoder. To change this mode,
press the middle button because it allows the entry into the
Setup Menu by pressing it for 5 seconds.
Usually this control parameter is set to "ON". It makes a brightness-linear
control possible. The normal non-linearity, produced by the SRC's phase
angle control, is thereby compensated. This function works in addition to
the " USER CURVES".
MDP-1219 Instructions page 22
2. Operating Guide
2.4 Setup Menu
2.4.2 DMX Mode
2.4.3 DMX /MIDI Input
2. Operating Guide
2.4 Setup Menu
2.4.4 MIDI Channel
