www.elationlighting.com



17EZKLING™UserManual

ARTNET_MMODE(ArtNet3Multicast)

IPAddressSet,SubNetMaskSet,andDMXUniverseOutputSet

Press the MODE button to select "ARTNET_M". The LCD display will show "OUT:TAPE" or

"OUT:DMX".SelectoneofthesetwomenuitemsbypressingtheUPorDOWNbuttons.

PresstheSETUPbuttontoselectIPAddressSet.TheLCDdisplaywillshow"ARTNETIP0:×××"then

presstheUPorDOWNbuttonstoenterthedesired3digitIPAddressofSection1,thenpressthe

SETUPbuttontoselect"ARTNETIP1:×××"andpresstheUPorDOWNbuttonstoenterthedesired

3digitIPAddressofSection2,thenpresstheSETUPbuttontoselect"ARTNETIP2:×××"andpress

theUPorDOWNbuttonstoenterthedesired3digitIPAddressofSection3,thenpresstheSETUP

buttontoselect"ARTNETIP3:×××"andpresstheUPorDOWNbuttonstoenterthedesired3digit

IPAddressofSection4.



Once the complete desired IP Address Set has been entered, continue by pressing the SET UP

buttonandtheLCD displaywillshow"SW0:×××",thenpresstheUPorDOWNbuttonstoenterthe

desired3digitSubnetMaskofSection1,thenpresstheSETUPbuttontoselect"SW1:×××"andpress

theUPorDOWNbuttonstoenterthedesired3digitSubnetMaskofSection2,thenpresstheSETUP

buttontoselect"SW2:×××"andpresstheUPandDOWNbuttonstoenterthedesiredthe3digitSubnet

MaskofSection3,thenpresstheSETUPbuttontoselect"SW3:×××"andpresstheUPorDOWN

buttonstoenterthedesired3digitSubnetMaskofsection4.

Once the complete desired Sub Net Mask has been entered, continue by pressing the SET UP

buttonandtheLCD display willshow"U:×××××",thenpresstheUPor DOWNbuttonsto enterthe

desireduniverseaddress“U:0000132768”andpresstheMODEbuttontoconfirmandexit.



NOTE: Allchanges madeto the ARTNET_Mmodeareautomatically alsomade to theARTNET_U

mode.ThesameappliestoallchangesmadetotheARTNET_Umode;thesearealsoautomatically

madetotheARTNET_Mmode.



FormoreinformationaboutArtNet,clickonthelinkbelow.

http://artnet.org.uk/
