26 EMOTION™ User Manual Ver. 1
COLLAGE CELL SELECTION
COLLAGE EDGE BLENDING
Variable Edge Blending controls are used with the Collage Generator controls to
allow for on-the-fly adjustment of blend overlap between projectors. These controls
allow more flexibility for sizing a collage to a given screen or projection surface, as
well as smoother blending if wider blend regions are used. Horizontal and Vertical
blend regions can be controlled independently of one another.
The Variable Edge Blend Horizontal and Vertical parameters allow 16-bit control of
the horizontal blend region width from 0% (hard edge) up to 50% of the image size.
COLLAGE EDGE BLENDING CURVE ADJUSTMENT
The Edge Curve Adjustment lets you select from a variety of detailed methods to
modify the blending curve to control the overlap of the adjacent projections. These
modifications should only take place after all other modifications are complete.
They give the final adjustment to the overlapped region to make the overlapped
edge virtually seamless.
DMX Value
Curve Type and Range
0
Standard Color Blend Curve – No Adjustment
1-33
Standard Color Blend Curve w/Intensity Reduction (1 = Max Reduction)
34
Standard Color Blend Curve – No Adjustment
35-63
Standard Color Blend Curve w/Intensity Addition (63 = Max Addition)
64-95
Grey Scale Blend Curve w/Intensity Reduction (64 = Max Reduction)
96
Grey Scale Blend Curve – No Adjustment
97-127
Grey Scale Blend Curve w/Intensity Addition (127 = Max Addition)
