ELED Fresnel 150 Cleaning

Due to fog residue, smoke, and dust cleaning the internal and exter-

nal optical lenses must be carried out periodically to optimize light

output.

1. Use normal glass cleaner and a soft cloth to wipe down the

outside casing.

2. Clean the external optics with glass cleaner and a soft cloth

every 20 days.

3. Always be sure to dry all parts completely before plugging

the unit back in.

Cleaning frequency depends on the environment in which the fixture

operates (i.e. smoke, fog residue, dust, dew).

ELED Fresnel 150 Trouble Shooting

Listed below are a few common problems the user may encounter,

with solutions.

Unit not responding to DMX:

1. Check that the DMX cables are connected properly and are

wired correctly (pin 3 is “hot”; on some other DMX devices

pin 2 may be ‘hot’). Also, check that all cables are connected

to the right connectors; it does matter which way the inputs

and outputs are connected.

Unit is not outputting 150W in DMX Mode:

1. Check the Output Setting. See page 7.

ELED Fresnel 150 2 Channel DMX Mode - Mode 1

Channel Value Function

1 0 - 255 DIMMING

0%-100%

2 0 - 255 STROBING

SLOW - FAST

ELED Fresnel 150 2 Channel DMX Mode - Mode 2

Channel Value Function

1 0 - 255 DIMMING

0%-30%

2 0 - 255 DIMMING

30%-100%

Locate and remove the unit’s power cord. Once the cord has been

removed located the fuse holder located inside the power socket.

Insert a flat-head screw driver into the power socket and gently pry out

the fuse holder. Remove the bad fuse and replace with a new one. The

fuse holder has a built-in socket for a spare fuse be sure not to confuse

the spare fuse with active fuse.

ELED Fresnel 150 Fuse Replacement

ELED Fresnel 150 1 Channel DMX Mode

Channel Value Function

1 0 - 255 DIMMING

0%-100%

Note: The dimming channels are master controlled by the

Output Setting Mode (XXX5). Therefore if the Output Setting

Mode is set to 100W, the dimming mode for each DMX mode

will have a max output of only 100W. To make the max output

at 150W, you need to change the Output Setting Mode. Please

see page 7 for the Output Setting Mode.
