17 ELAR Q1™ User Manual ver 1
POWER LINKING
Max number of ELAR Q1
™
units connected to each ELAR Q1 PSU
™
power supply is (15),
which means you will need (1) power supply for every (15) fixtures.
SYSTEM EXAMPLE (30 Fixtures)
The table below provides a material list of required cables and power supplies to
install a system of (30) ELAR Q1
™
fixtures. See the System Install Diagram Example on
the next page for further details.
MATERIAL LIST TO INSTALL A SYSTEM OF (30) ELAR Q1™ FIXTURES
QTY
SKU#
DESCRIPTION
30
EAR913
ELAR Q1™ FIXTURE
1
60413010144
ELAR Q1 IP STARTER Y-CABLE
1
60413010149
ELAR Q1 IP EXTENSION Y-CABLE
2
EAR925
ELAR Q1 PSU™ POWER SUPPLY
2
60413010146
ELAR Q1 PSU IP POWER CABLE 3.3 ft. (1m)
OPTIONAL ITEMS TO SUPPORT ADDITIONAL FIXTURES AND/OR DISTANCES
~
EAR925
ELAR Q1 PSU™ POWER SUPPLY
~
60413010146
ELAR Q1 PSU IP POWER CABLE 3.3 ft. (1m)
~
60413010144
ELAR Q1 IP STARTER Y-CABLE
~
60413010149
ELAR Q1 IP EXTENSION Y-CABLE
~
60413010145
ELAR Q1 IP EXTENSION CABLE 3.3 ft. (1m)
~
60413990038
ELAR Q1 EXTENSION CABLE 9.8 ft. (3m)
NOTE: Additional items such as mounting hardware, electrical wire, plugs, junction
boxes, and power/data cables may be required, depending on your specific
system design needs.
