Overview
Front View
1
2
3
4
5
6
7
8
9
7. 128x160 color LCD Display
Shows the current activities.
8. LEFT/RIGHT/UP/DOWN/OK Button
Used to select function.
4. DMX IN Indicator
This LED blinks when DMX signal inputs.
5. MIDI Indicator
3. DMX OUT Indicator
This LED blinks when sending DMX signal.
6. SMPTE Indicator
This LED will blink when an available SMPTE time received in SMPTE/MIDI
Trigger mode.
10. PLAY/PAUSE/STOP Button
Used to select the running status of memory in Manual mode.
This LED will blink when an available MIDI time received in SMPTE/MIDI Trigger
mode.
-3-
10
1. USB Port
Connects to PC for communications and program updating.
2. SD Card Port
Use to insert SD card for data transmission.
11. BLACK OUT Button
Controls DMX output in Manual mode.
1
1
9. Memory 1~8 Button
Used to select the memory you want to play in Manual mode.
