Thanks for you purchasing DMX Recorder Pro Rack. The present content pretends to make a description of
the technical features, Specifications and operation, etc.
-
-
-
-
-
-
-
-
-
128x160 Characters color LCD display
Up to 8 memories with individual Master setting allows users to assign Scenes, Chases or Shows.
Consisting of 5 operation modes: Manual control, Real-time trigger, SMPTE/MIDI time code trigger, DMX trigger and
DMX monitor
Over 5 hours recording time for Show and up to 4 different recording modes available, including Manual, Auto, Semi-
Auto and Smart
Allows to record SCENE, create CHASE and set Fade/Hold time for every step of the CHASE.
Password lock function
3pin XLR DMX male/female connector, SD card port, USB port, 3pin SMPTE port and 5pin MIDI input
External Dry Contact available
- Programme updatable
Standard DMX-512(1990) and DMX-1000K(1M) protocol compatible
-2-
General Instructions
Features
Descriptions
Technical Specification
HOUSING
LISTING
CONNECTOR
POWER INPUT
COMPLIANT PROTOCOLS
LCD DISPLAY
Metal sheet with powder finishing
CE certified
OPERATING TEMPERATURE
STORAGE TEMPERATURE
INGRESS PROTECTING RATING
DIMENSIONS
WEIGHT
-10 degC to +50 degC
-20 degC to +70 degC
IP20
482(L) x 78(W) x 44(H)mm
1.2kg
DC9-12V, 500mA Min
3-pin XLR connectors for DMX in/out,
Standard DMX-512(1990) and
DMX-1000K(1M) protocol compatible
USB port for communicating with PC
128x160 Characters
3pin SMPTE input, 5pin MIDI input
,
Physical Dimensions
Unit: mm
