27 ACL 360 BAR™ User Manual
MODE / CHANNEL
VALUE
FUNCTION
USER A
USER B
USER C
16
14
12
CHASE MACROS - NOTE: Color Must Be Selected To Engage Macros.
0-14
LEDs OFF
15-30
01 - Single LED Chase Sequence #1
31-46
02 - Center LED ON then 2 Single LEDs Burst Out Towards Both Ends
47-62
03 - Single LED ON then Alternating Single LEDs ON
63-78
04 - Single LED ON to Other LEDs ON in Same Direction Sequence
79-94
05 - 2 LED Array Chase Sequence
95-110
06 - Single LED Chase Sequence #2
111-126
07 - 4 LED Array to 3 LED Array Transition Sequence
127-142
08 - 3 LED Array Chase to Opposite Side Sequence
143-158
09 - 3 LED Array to 4 LED Array Flash Sequence
159-174
10 - 4 LED Array Chase To Opposite Side Sequence
175-190
11 - Single LED to Remaining 6 LEDs Fill In to Opposite Side Sequence
191-206
12 - Outer 3 LEDs Alternate Flash then Center LED Flashes Sequence
207-222
13 - Alternating 2 LED Array Flash Sequence
223-238
14 - Single to 7 LED Array ON then OFF in Same Direction Sequence
239-255
15 - Various LED Array Chase Sequence
17
15
13
CHASE SPEED
0-125
FAST to SLOW
126-130
STOP (SPEED = 0)
131-255
SLOW to FAST
18
16
14
CHASE FADE
0-255
Fade Chase
20
18
16
RESET, INTERNAL PROGRAMS
0-79
Normal
80-84
ALL Motor Reset
85-87
Scan Motor Reset
88-90
NO FUNCTION
91-93
NO FUNCTION
94-96
NO FUNCTION
97-99
NO FUNCTION
100-119
Internal Program 1 (scene1~8 of EEPROM)
120-139
Internal Program 2 (scene9~16 of EEPROM)
140-159
Internal Program 3 (scene17~24 of EEPROM)
160-179
Internal Program 4 (scene25~32 of EEPROM)
180-199
Internal Program 5 (scene33~40 of EEPROM)
200-219
Internal Program 6 (scene41~48 of EEPROM)
220-239
Internal Program 7 (scene49~56 of EEPROM)
240-255
NO FUNCTION
