- 17 -
11) The site for recharging should be well ventilated. It is prohibited to smoke
or use open fire, avoiding the risk of hydrogen explosion.
12) The electrolyte in accumulator is toxic and corrosive. For this reason,
always wear working suit and protection glasses to protect your body from
contacting the electrolyte in accumulator.
13) If your clothes, skin or eyes are spilled with acid liquid in accumulator,
flush with large amount of clean water. For skin and eyes, flush with large
amount of clean water and also seek doctor’s treatment immediately. Acid
spillage must be neutralized and treated immediately.
14) The weight and dimensions of the accumulator have remarkable effect on
stability of the stacker. Therefore do not modify the type of accumulator
without approval from the manufacturer.
15) Never discharge in large current, for example, performs travelling and
lifting simultaneously.
4.4.4 Disposition of worn-out accumulators
Worn-out accumulators should be recycled according to local regulations, and
stored in specified zone or cast-off treatment zone. These works should be done
by qualified specialized companies.
4.4.5 Specification of the accumulator
Battery
Charger
Rated power：
24V
Rated capacity：
100/120Ah
Input：195/265VAC
50/60Hz
Output：
DC24V20A
Uninsulated terminal poles on the accumulator should be protected with an
insulated cover. When connecting the accumulator and socket, make sure to stop
the stacker and put the switch at position “0”.When replace or install the
accumulator, make sure the accumulator is fixed securely in battery box.
4.4.6 Storage, transportation and installation of the accumulator
The stacker must be parked on the level ground steadily. To prevent short
circuit, naked cable ends and the terminal posts should be covered with insulated
covers. When pulling out the accumulator, properly arrange removed
accumulator's connectors and cables without blocking access of the accumulator.
When install or remove the accumulator with a crane, make sure the load
capacity is sufficient (weight of the accumulator is marked on both the
nameplates of the accumulator and the stacker.) The crane must pull vertically to
