Specifications | 9
63
9 Specifications
9.1 List of Specifications
9.1.1 Decoding Process
Interlaced video streams cannot be displayed.
Number of cameras that can be displayed
simultaneously
32 (Max.)
Number of cameras that can be registered 48 (Max.)
Camera protocol ONVIF Profile S, AXIS VAPIX, Panasonic/i-PRO,
RTSP
Video compression formats H.265, H.264, MJPEG
Audio compression formats AAC, Opus, G.711, G.726
Communication protocols DHCP, DNS, HTTP, HTTPS, LDAP, LDAPS,
NTP, RTP, RTSP, SNMP, SRT, IEEE802.1X
Streaming protocols RTP (H.265, H.264, MJPEG, MPEG2-TS), SRT
(H.265, H.264), UDP (MPEG2-TS)
Bit rate 8192 kbps (Max)
Maximum resolution H.265, H.264: 3840 x 2160
*1
MJPEG: 640 x 480
Maximum frame rate 60 fps
*2
*1
If the maximum resolution is exceeded, the image will not be displayed. Lower the resolution and
bit rate of the camera.
*2
The maximum frame rate depends on the resolution (refer to 9.2 Decoding Performance [}64]).
9.1.2 Network
Wired LAN standard RJ-45 (1000BASE-T, 100BASE-TX)
9.1.3 Power
Input PoE+ input: IEEE802.3at Type2
AC adapter: DC 12 V ±10%, 2.0 A
Maximum power consumption PoE+ input: 25.5 W
AC adapter: 24.0 W
9.1.4 Physical Specifications
Dimensions 165 mm x 44.2 mm x 130 mm (W x H x D)
Net weight Approx. 720 g
9.1.5 Operating Environment Conditions
Temperature 0 ˚C – 40 ˚C
Humidity 20 % – 80 % R.H. (no dew condensation)
Air Pressure 540 hPa – 1060 hPa
