34

Chapter 3 Basic Usage

3.

Adjust each item while viewing the monitor screen.

Attention

• Manually adjustable items will vary by the target settings. Items that cannot be adjusted will not be displayed

on the screen.

Note

•

Clicking

resets the manual adjustment results of each item.

Item Description

Brightness

It adjusts the monitor brightness. Use the slider or the

and buttons to specify

a value. Depending on the monitor you use, the unit of measure for brightness is

di󰀨erent. (cd/m

2

or %)

Black level It adjusts the brightness of the darker area of an image displayed on the monitor.

Specify a value using the slider.

Note

• Increasing the black level reduces the contrast.

White point

Use

and buttons or use your mouse and drag the circle ( ) inside the white

point area to adjust the white point.

Gamma (EOTF) Specify a value using the slider.

6 colors

Click the blue circle (

) inside the hexagon or the letters R/G/B/C/M/Y to specify

each color level. Then, use the slider for hue, saturation, and lightness settings to

adjust the color.

Attention

• Adjustments will not be necessary in most cases.

Preview With the checkbox selected, you can make adjustments while viewing the status

changes made to the monitor.

Show pattern A test pattern used for visually checking the adjustment status will be displayed in

full-screen.

Reset all All the values are restored to the initial values when the manual adjustment was

started.
