23
Preparation
When drilling in blocks, make sure that these blocks are well ancho-
red and secured.
Make sure that the statics are not violated before drilling into load-
bearing parts. Follow the instructions of the professionals responsible
for the planning.
Make sure that no gas, water or electricity lines are damaged during
drilling.
Be careful not to touch any metal parts of the machine when drilling
through walls or floors. In these areas, power cables may be located
under water.
Care should be taken to ensure that the drill core does not fall and
cause injury to persons or damage to property. Clear and secure the
work area.
Install a suitable device to contain the drill core if it could cause da-
mage when it falls out.
Make sure that the drill bit is properly secured.
Use the correct tool for the material to be worked.
Fastening of the Drill Rig
The diamond core drilling machine EBM 250/2 RP may be operated only
when it is mounted in a drill stand. We wish to point out a few important
mounting variants, since the drill stand is not included in the scope of
delivery. The operating instructions for the drill stand must be observed.
When using a vacuum fastening, make sure that the vacuum is sufficiently
strong (at least -0.8 bar). The seals must not be worn.
Caution! Not for wall and ceiling drilling!
Do not forget that you can only unscrew the levelling screw to a
certain point in order not to destroy the vacuum.
The most commonly used type of mounting is the plug mounting.
If possible, use metal plugs. The plug diameter must not be smaller than
12 mm.
To properly mount the drilling unit, you need the mounting set (order
no. 35720000).
Drill a hole with a diameter of 16 mm, 50 mm deep and remove dust.
Insert an anchor and expand it using the setting tool.
Screw the threaded rod into the anchor.
Place the drilling unit with the slot in the foot on the threaded rod.
Put the disc on and screw the wing nut on tightly.
Adjust the drilling unit using the four screws in the base plate.
