14
Use
After each readjustment always check that the screws are
tightly fixed so that safe operating of the drill rig is possible.
Mounting the turnstile
■ Mount the turnstile (1) on the
right or left side of the carriage (2)
depending on the work to be
performed.
■ Check whether the turnstile (1)
is fixed tightly.
Fastening of the drill rig
Hole centering indicator:
The drill rig is fitted with a hole centering indicator for easy and precise
positioning.
Mark the center of the hole to be drilled.
Fully extend the hole centering indicator (see fig.).
Position the drill rig in such a way that the tip or the
groove of the indicator points precisely to the hole
center mark.
After the drill rig has been fastened, put the hole center
indicator back in its original position.
Assembly Machine
about quick connection:
about adapter collar clamping:
tip groove
