13
Fastening of the Drill Rig
Position the rig at the desired location.
The surface must be completely level and smooth.
It is imperative that the support bolt (D) be turned upward before aspirating
since the stand sinks toward the surface during aspiration. If the plate for the
support bolt is located on the surface during aspiration, then the device will not
aspirate sufficiently.
Press the vacuum suction cup (B) firmly against the surface to be aspirated.
The rubber disk must be lying flat as you do this.
Press the plunger (C) several times to create a vacuum.
A sufficient vacuum has been created if the red ring on the plunger is no longer
visible and the plunger stays in the pump. When pumping, always ensure that
the pump plunger moves smoothly. After aspirating, the plunger must be freely
accessible for re-pumping. If the vacuum decreases, the holding force must be
restored by re-pumping.
The support bolt (D) increases the drilling unit's stability during drilling and must
be adjusted so that it sits firmly on the working surface.
Vacuum deactivated Vacuum activated
CAUTION!
Never activate the ventilation valve (F) during drilling.
The rig can be additionally secured by holding it firmly by the handle (E)
with one hand.
To release it, activate the ventilation valve (F) until the vacuum has completely
subsided.
Attention!
The holding capacity is significantly reduced up to its total loss in cold,
humid or dirty conditions, in particular if the suction pad is not
maintained or is damaged.
Vacuum suction feets must not be subjected to extreme heat (e.g. open
flames, constant direct sunlight). Temperatures consistently above
approx. 40°C must be avoided at all costs.
