56 VOLT LITHIUM-ION CORDLESS GRASS TRIMMER — ST1620E-T12
the tool to protect the user! When the guard is fixed,
never attempt to remove or adjust the guard, if a
replacement is needed, it should be performed by a
qualified service technician!
Align the two bolts, which are pre-assembled on the
guard, with the two screw holes in the shaft (Fig. D),
and then tighten them with the supplied hex wrench
(Fig. E).
Make sure the guard is fixed according to Fig. D & E,
any reverse fixing will cause great danger!
MOUNTING AND ADJUSTING THE FRONT-ASSIST
HANDLE
1. Loosen and remove the quick release lever and wing
nut from the front handle (Fig. F).
2. Push the front handle onto the shaft within the
mounting zone between the height-locking clamp
and the hinge (Fig. G).
3. Insert the clamping block into the handle slot (Fig. H).
4. Mount the quick-release lever and pre-tighten
the wing nut. Make sure that the front handle is
positioned upwards and points toward the top of the
rear handle (Fig. I).
5. Pull the quick-release lever up to move/rotate the
front handle to a comfortable operating position
(Fig. J).
NOTICE: The front handle should be positioned on the shaft
only within the mounting zone (Fig. J).
6. Engage the quick-release lever to secure the front
handle in place.
WARNING: Never use the trimmer without the
front handle securely attached.
ADJUSTING THE TRIMMER HEIGHT
If the length of the shaft is not suitable for operation, you
can adjust the length of the shaft with the height-locking
clamp.
1. Remove the battery pack from the trimmer.
2. To adjust the trimmer height (i.e., shaft length), open
the height locking clamp, and then slide the shaft
up or down to desired height, securing it in place by
depressing the height-locking clamp. (Fig. K)
NOTICE: The front handle may need to be repositioned
after the trimmer height is changed.
ATTACHING SHOULDER STRAP (MODEL NUMBER:
AP1500)
For safe and better operation, put the strap over one of
your shoulders and across your back.
1. Loosen the screw knob and hex nut from the
shoulder strap loop.
2. Attach the shoulder strap loop onto the shaft within
the installation zone (Fig. L1).
3. Tighten the screw knob and hex nut.
4. Depress the shoulder strap carabiner to open it and
attach the shoulder strap to the strap loop (Fig.L2).
5. Adjust the shoulder strap length and placement to
a comfortable operating position – hold the trimmer
with both hands: one hand on the rear handle and the
other hand on the front handle (Fig. L3).
WARNING: When an emergency occurs, take the
shoulder strap off from your shoulder immediately, no
matter what way the strap is on.
OPERATION
WARNING: Do not allow familiarity with this
product to make you careless. Remember that a
careless fraction of a second is sufficient to inflict
serious injury.
WARNING: Always wear eye protection. Failure
to do so could result in objects being thrown into your
eyes and other possible serious injuries.
Before each use, inspect the entire product for
damaged, missing, or loose parts such as screws,
nuts, bolts, caps, etc. Tighten securely all fasteners
and caps and do not operate this product until all
missing or damaged parts are replaced.
WARNING: To prevent serious personal injury,
remove the battery pack from the tool before
servicing, cleaning, changing attachments or
removing material from the unit.
You may use this product for the purposes listed
below:
Trimming: used for removing grass and weeds up
against walls, fences, trees and borders.
Cutting: used for cutting the grass that is difficult to
reach using a normal mower.
NOTICE:
The tool is to be used only for its prescribed
purpose. Any other use, for example edge trimming, is
deemed to be a case of misuse.
