56 VOLT LITHIUM-ION CORDLESS MISTING FAN — FN1000E 11
EN
4. Connect the garden hose to the water line.
5. Install the battery pack.
6. Press the power button to turn the fan on.
7. Open the water tap fully, the fan will start misting.
NOTICE: The recommended maximum working pressure
should not exceed 80 psi.
NOTE: Even if there is no power, the fan will start misting
when the water tap is turned on.
8. Press the misting mode button to select the msiting
mode for better working results.
NOTE: The small opening in the garden hose adapter
makes it susceptible to hard water and mineral deposit
build up. Clean the adapter frequently and use white
vinegar or other de-scaling agent to remove the buildup.
Using the Fan without Misting
If desired, this product may be used as a fan only, when
not connected to a water source. When not in use, always
coil the intake tube into its storage area (See section
“TRANSPORTATION AND STORAGE” in this manual) to
protect it from damage and contamination.
COMMUNICATION TECHNOLOGY
For information on our full range of connected products
and services, including connection instructions, please
scan QR Code below or visit
www.egopowerplus.eu/connect.
ELECTRONICS PROTECTION
When the oscillating function is activated but the fan does
not oscillate, the oscillating indicator will display three
flashing green lights continuously to remind the operator
to check whether the fan head is stuck, and remove any
foreign matter that stuck on the fan head before restarting
the feature.
When the misting function is activated but no water mist
is coming out:
◾ The water pump will keep running for a short while,
and then stop automatically to protect internal
electronics.
◾ The misting indicator will display three flashing green
lights continuously as an alert for the operator to:
a. Check if the intake tube is properly immersed into
water.
b. Check if the misting nozzle(s) is clogged, and
clean according to the “NOZZLE MAINTENANCE”
chapter.
c. Press the misting mode selection button to restart
misting.
When the battery charge is low, the power button will
flash green light to remind the operator to charge or
change battery pack.
When the battery pack or fan is too hot, the power button
will flash red light to warn the operator to turn off the fan
and allow the battery pack or misting fan to cool until
the temperature drops to the recommended operating
temperature range before restart the fan.
MAINTENANCE
WARNING: When servicing, use only identical
replacement parts. Use of any other parts may create a
hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualified
service technician.
WARNING: To avoid serious personal injury, always
remove the battery pack from the product when cleaning
or performing any maintenance.
GENERAL MAINTENANCE
All misting fan service, other than the items listed in
these maintenance instructions, should be performed by
competent misting fan service personnel.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake fluids,
petrol, petroleum-based products, penetrating oils,
etc., come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may result in
serious personal injury.
WARNING: When cleaning the misting fan, DO NOT
immerse it in water or other liquids.
