To add vlan, enter a VID and select vlan member for this entry from vlan member list. Now select “Add” button to
add vlan entry to the table. Vlan entry can be modified by selecting VID from the list and then select “Update”
button.
To delete an entry from the vlan table, select VID from the drop-down list and select “Delete” to remove the
corresponding entry from the table.
2.6.3 Multi to 1 Setting Configuration
Choose VLAN Setting > Multi to 1 setting, and the following page appears. This feature can disable
communication between ports in order to improve the security.
After setting the multi to 1 setting, the VLAN original setting will be cleared. If the VLAN is configured again,
the multi to 1 setting will be cleared.
Multi to 1 Settings take effect only when “VLAN based on port” mode is selected.
In this page, select the current port from the drop-down list. Then select the port from the check box to isolate
from the current port.
2.7 Per Port Counter
Choose Per Port Counter, and the Port Counter submenu is shown as below.
Choose Per Port Counter > Port Counter and the following page appears. In this page, you can view the packet
quantity.
