14
6. TECHNICAL DATA
USER/INSTALLER
6.1. Technical data according to the product standard Sense 8
The data shown is indicative and obtained during the certification phase at a notified body according to current
regulations.
The results are obtained with calibration according to the installation or and possible closed glass cleaning. It is the
responsibility of the installer to use the gasket supplied (if available) and to adjust the parameters.
Quantity
SENSE 8
Rated power
Reduced power
Output power
7,9
2,6
kW
Yield
85
90,8
%
CO emissions at 13% O
2
0,018
0,021
%
Smoke temperature
174
87,4
°C
Fuel consumption
1,9
0,6
kg/h
Hopper capacity
15
kg
Draught
11,3
11,6
Pa
Autonomy
8
25
Hours
Minimum volume of installation room
26
m
3
Heatable volume
205
m
3
Smoke duct diameter
80
mm
Air intake duct diameter
40
mm
Weight with packaging
142
kg
Energy efficiency class (Regulation
1185/2015)
A+
Environmental Class according to the
Italian Ministerial Decree 186
3 stars
Minimum distance of combustible
materials from Back/Side/Front
50/50/800
mm
Minimum distance of combustible
materials from Ceiling/Floor
NPD: (No declared
performance)
mm
NOTES ON THE TECHNICAL DATA
To calculate consumption, a heating value of 4.8 kW/Kg was used.
The heatable volume is calculated considering a heat demand of 33 Kcal/m³ per hour.
The autonomy may vary depending on the use/installation/fuel characteristics and it is not a contractual
obligation, nor is it a possible cause for dispute.
The product can work safety also with a higher draught. However, an excessive draught may result in switch-off
and/or decreased efficiency.
