13
Installing the Door Handle
To install the door handle:
1. Open the door and carefully pull the door gasket around the area where the handle is to be
installed.
2. Carefully remove the two pre-installed decorative plugs from the front of the door.
3. Insert each Phillips head screw through the gasket side of the door until the screw passes
through the door.
4. Align the handle with the screws and tighten using a Phillips head screwdriver until the handle
isushagainstthedoorframe.
5. Carefully press the door gasket into its original position.
Note: Some commercial refrigerators do not have decorative plugs installed.
Caution: Do not over-tighten the screws as this may cause damage to the handle or to
the stainless steel door.
!
Phillips Screw
Hex Screw
Back of the cooler
0 - 2 3/4”
Side View
Top of the cooler
The mounting piece is arranged
in the corresponding screw holes
on both sides of the top of the body.
Top of the Cooler
3 /”
2”
/”
Top View
/”
Installing the Anti-Tip Brackets
To install the Anti-Tip Brackets:
1. Determine the distance behind the unit you will want for your installation.
2. Secure the brackets to top of the unit using one (1) provided Phillips screw in each bracket.
3. Secure the brackets to the wall using one (1) provided hexagon screw in each bracket.
Note: The Anti-Tip Brackets are optional and are not a requirement for installation.
The refrigerator comes with anti-tip brackets to secure the top of the cooler to the wall behind it.
Instructions are provided below for installing the Anti-Tip Brackets.
