Use and maintenance manual, model “LIBERA 8 V/C - LIBERA 11 V/C”
ENGLISH
7
• parts subject to normal wear and tear such as
gaskets, glasses, coverings and cast-iron grids,
painted, chromed or gilded details, handles,
electric cables, lamps, ignition resistors, lights,
knobs, and all parts that can be removed from
the hearth (e.g., refractory panels, brazier) and/or
directly exposed to re;
• colour changes in the paint of ceramic parts, as
well as cracks of the ceramic, as they are natural
features of the material and naturally deriving
from normal use;
• masonry;
• other system details (if any) not supplied by the
manufacturer.
Any technical interventions aimed at restoring
the product must be agreed with the Authorized
Technical Assistance Centre, which reserves the
right to accept the assignment or not. Technical
interventions are subject to fees according to the
rates in force.
Moreover, any expenses needed for remedying
incorrect technical interventions, tampering or, in
any case, factors harmful to the appliance and
not attributable to manufacturing defects will also
be charged to the user.
Without prejudice to the limits imposed by laws
or regulations, any guarantee of containment of
atmospheric and noise pollution is also excluded.
1.8 SPARE PARTS
Use only original spare parts.
Do not wait for components to wear out before
replacing them.
In the event of product malfunction, this helps to
prevent accidents caused to people, animals or
things.
To replace spare parts, consumables, and to carry
out extraordinary maintenance, it is recommended
to contact an authorized technician.
1.9 IDENTIFICATION PLATE
An identication plate, to be found on the back
of the product, shows all the product technical
information, including the Manufacturer's data,
serial number and CE marking.
1.10 PRODUCT DISPOSAL
Responsibility for the demolition and disposal of the
product is borne solely by the owners, who must
act in compliance with the laws in force in their
country with regard to safety and environmental
protection.
At the end of its useful life, the product must not
be disposed of together with municipal waste.
It can be delivered to the local separate waste
collection centres provided by the municipal
administrations, or to the retailers providing such
service.
Disposing of the product through separate waste
collection helps to avoid possible negative
consequences for both environment and health
which can derive from inappropriate disposal.
This also allows the recycling of materials and
obtain signicant savings in terms of energy and
resources.
1.11 HERMETIC PRODUCT
Products built with a fully airtight structure do
not consume room oxygen, as they take the air
from outside the building (if properly installed)
and can, therefore, be placed inside all houses
with a high degree of insulation, such as “passive
houses" or highly energy-efcient. Thanks to such
technology, there is no risk of smoke emissions into
the environment and, therefore, there is no need
for ventilation grids.
Hermetic products can also be installed in the
presence of forced ventilation or in rooms where
pressure can be lower if compared to the outside.
2 WOOD FEATURES
PELLETS
Wood pellets are a type of fuel made of pressed
wood sawdust, often recovered from carpentry
processing waste. The material used cannot
contain any foreign substances, e.g., glue,
lacquer, or synthetic substances.
After being dried and cleaned of impurities,
sawdust is pressed through a matrix: due to the
high pressure the sawdust heats up, activating the
natural binders of the wood; in this way, pellets
maintain their shape even without the need for
additional articial substances. The density of
wood pellets varies depending on the type, and
can exceed that of natural wood by 1.5 - 2 times.
The cylinders have a diameter of 6 mm and a
length varying between 10 and 40 mm.
Their density is approximately 650 kg/m3. Due to
the low water content (<10%), they have a high
energy content.
The main quality certications for pellets existing
on the European market allow us to guarantee
that the fuel falls into class A1 according to ISO
17225-2:2014 (formerly known as EN 14961).
Examples of these certications are, e.g., ENPlus,
DINplus, Ö-Norm M7135, which guarantee that
the following characteristics are met:
• caloric value: 4.6 ÷ 5.3 kWh/kg;
• water content: ≤ 10% of weight;
• percentage of ash: max 1.2% of weight (less than
0.7% according to A1);
• diameter: 6±1/8±1 mm;
• length: 3÷40 mm;
• content: 100% untreated wood, without any
