Use and maintenance manual, model “LIBERA 8 V/C - LIBERA 11 V/C”
ENGLISH
28
the instructions as described in the following
paragraph.
The product must never work with pellets and
wood logs at the same time, as this may overheat
the combustion chamber and damage the
appliance. Ignoring the above-mentioned
instructions will invalidate the product warranty.
Never open the door when the product is working
in pellet mode. In case the door is nonetheless
open during operation, the system will ask whether
you have inserted wood logs into the hearth.
If you answer YES or do not answer at all, the
software will shut down the product. This is further
proof of the fact that it is not possible to burn
wood by exploiting pellet combustion.
When the product is switched on for the rst time,
unpleasant odours or fumes may be generated
due to the evaporation or drying of some of the
materials used. Such phenomenon will disappear
after a few hours of use. During this period, it is
advisable to keep the premises well ventilated.
Below is the sequence of operations to be
performed to optimize the product start-up:
1. Clean the surface of the combustion chamber,
removing any residues left from previous use.
2. Push the air adjustment handle upwards;
Below are the dimensions of the combustion
chamber:
Width: 34 cm.
Height: 45 cm.
Depth: 32 cm.
3. On the shelf of the combustion chamber,
prepare a multi-level ignition module as
follows:
• 2 dry logs on the shelf, about 30 cm long and
weighing about 0.7 kg each;
• 2 levels of thin pieces of rewood (about 20-25
cm long) to ignite the ame, as shown in the
gure.
4. Place the natural relighter (ame) on top of
the ignition module.
5. Keep the door slightly open to allow the ame
to develop, so that the combustion can easily
spread to the top row of rewood.
6. Close the door.
DO NOT OVERLOAD THE PRODUCT AND FOLLOW
THE RECOMMENDATIONS ON TYPE AND QUANTITY
OF WOOD TO BE USED! The tertiary air holes on
the back of the combustion chamber must never
be blocked. Exceeding the recommended rell
quantities may damage product, thus voiding
the warranty. An excessive load, will result in poor
combustion and will lead to excessive smoke
temperatures, which can damage the product,
the smoke duct and ue.
All the external surfaces of the product reach high
temperatures. Always remember to use all due
precautions when touching the product surface.
It is recommended to keep the combustion-air
handle open for the entire duration of the rst
load (after ignition) to allow both the combustion
chamber and the smoke duct to heat up to the
right temperature, and to prevent the ame from
extinguishing.
When the stove is running and - above all -
during the heating and cooling phases, ticking
noises may be heard. These are due to thermal
expansion/contraction of the materials due to
changes in temperature throughout operation.
Do not keep the re door open during operation.
The re door can be opened only for the time
needed to load the wood. To avoid excessive
leakage of combustion smoke into the room, it is
recommended to open the door slowly.
11.3 COMBUSTION ADJUSTMENTS
Once both the combustion chamber and the entire
ue pipe have reached the right temperature, it
is possible to optimize combustion by adjusting
