27
PRECAUTIONS
PACKAGE
CONTENTS
DESCRIPTION
&
FEATURES
INSTALL
&
CONNECT
START-UP
&
OPERATION
PANEL
FUNCTIONS
TECHNICAL
DATA
6.2.2 REAR PANEL
6. RS-232: Serial port for remote control. Signal pass-through supported.
7. AUDIO OUT: The audio port acts as an audio de-embedder from HDMI.
8. LAN (PoE) CONNECTOR: Connect the 1Gb network port to an Ethernet switch to
begin data transmission. When PoE on the Ethernet switch is available, the device
will not need to be locally powered.
9. LINK indication (Green):
o Light ON: The network cable is correctly connected.
o Light OFF: No Network connection.
10. DATA Indicator (Yellow):
o Flashing: Data transmission.
o Light OFF: No Data transmission.
11. HDMI OUT: HDMI output port.
12. DC 12V PORT: Connect this port to the 12VDC included power supply.
