4. Copy EDID from: Use the mouse to click the white dropdown to complete the
corresponding EDID switch. The dropdown will show the current EDID information.
5. User EDID selection:
o Click the whitebox, select EDID, then select user1 ~ 4 in the box, and finally
click apply.
o Click browse and select the path where the bin file is located, then select user1
~ 4 in the box and finally click Upload. The EDID can be imported into user
EDID.
• EDID Management
The device includes 4 EDID modes: Default EDID, User EDID, Output EDID,
Temp1, control EDID by WEB and RS-232. Factory Default: Default1 4K60 444
2CH.
Refer to the EDID management commands in the table below
.
Instructions are as follows:
Send instruction: “#edid_d input=1 mode=1 data=2”. The input parameter
“input” must be 0 or 1~8 (0 means all inputs), data =0~24 (corresponds to the
following table).
