(7)
The electrical infrastructure supplying the EV chargers can deliver 50 A.
EV charger 1 EV charger 2 EV charger 3
Dynamic load balancing enabled Yes N/A N/A
Mode Master Node Node
Phase balancing limit See Section 7.3 N/A N/A
Energy meter enabled Yes N/A N/A
Maximum current for the charging site
(7)
50 A N/A N/A
Maximum current for the building 100 A N/A N/A
Prioritize this charger Yes No No
Table 17. Example of dynamic load balancing
Example
The installation can go up to 80A, in the case below even if we have external load the energy meter will detect them, so we don’t
have to worry about them. We can set ‘Available max current to charging site and Maximum current for the building at the same
value 80A.
For an energy meter reading of 80 A
The algorithm, in this case, will subtract the energy meter reading from the ”Maximum current for the building”: 100 A – 80 A
= 20 A. This value is LOWER than the “Maximum current for the charging site”, therefore this value (20 A) is used as the total
available current for EV charging. EV charger 1 has a priority over other chargers, means that most, if not all, of the current
capacity will be used by EV charger 1.
For an energy meter reading of 20 A
The algorithm, in this case, will subtract the energy meter reading from the ”Maximum current for the building”: 100 A – 20 A
= 80 A. This value is HIGHER than the ”Maximum current for the charging site”, therefore the parameter Maximum available
current for EV charging (50 A) is used as the total available current for EV charging. EV charger 1 has priority, meaning that it will
charge the fastest, while EV chargers 2 and 3 will share the remainder of the total available current capacity.
In case there is no sufficient current available to charge the vehicle, the EV charger will change the status of the
charging session to “Suspended.” The LED strip on the front of the EV charger will indicate the status with a pulsating
blue light. Once enough current is available for the charging session to be resumed, the EV charger will revert to the
“Charging” mode. The LED strip on the front of the EV charger will indicate the status with a chasing blue light.
51GREEN MOTION BUILDING INSTALLATION MANUAL MN191028EN April 2024 www.eaton.com
