Step 4. Use the communication cable gland to route the cable (refer to Figure 21).
Step 5. Connect the wires to the front cover, carefully reassemble the platform, and close the unit.
When using both cables, use labels to distinguish the ports: ETH0 (left port), ETH1 (right port).
Green Motion Building EV chargers that support 4G WAN connectivity should be equipped with a 4G SIM card during
installation (not provided with the unit). When selecting a SIM card for the EV charger, the specifications below should
be respected.
6.8 4G LTE Connection
In scenarios where Green Motion Building EV chargers are connected in a master-node network, it
is strongly recommended to upgrade the firmware of the EV charger configured as the Master first,
followed by upgrading the firmware of the EV chargers configured as Nodes.
It is strongly recommended not to use SIM cards available over the counter that operate on public APNs,
as those are not meant for IoT commercial products and are considered to pose a cybersecurity risk.
In network installations where a single EV charger is used to route the traffic for the entire network, data
usage will be multiplied by the number of EV chargers in the network.
6.8.1 Technical Specications
Network: 4G LTE
Type: 2FF mini SIM card
Choose a service provider that is operating on a private access point name (APN) and provides an option to encrypt
data communications using either a VPN or IPSec protection for 4G communication. Sim card should provide the
following features:
Universal integrated circuit card (UICC) pin support to prevent unauthorized access to network,
Security measures against theft and SIM card cloning.
6.8.3 Installation instructions
Follow the steps below to equip the EV charger with the SIM card.
Step 1. Open the Green Motion Building EV charger. See Section 5.2
Step 2. Locate the sim card slot on the upper left corner of the PCBA platform.
Step 3. Insert the SIM card. Ensure it is not loosely fitted.
6.8.2 Data consumption
The amount of data transferred between an EV charger and the backend server may vary, based on the network
structure. It is recommended to select an unlimited data plan or at least a data plan that takes into account the usage
pattern listed below:
The expected average monthly data traffic may reach up to 80 MB per EV charger.
An additional annual data usage of up to 500 MB should be considered for firmware and feature updates twice a
year per EV charger.
44
GREEN MOTION BUILDING INSTALLATION MANUAL MN191028EN April 2024 www.eaton.com
