Je bekijkt pagina 7 van 19
4
Interface/Key
USB Interface
1 x USB: Type-C
Video Interface
1 x HDMI: 1.4b
Network
Interface
1 x LAN: 10M/100M Adaptive
Ethernet Port
Audio Interface
1 x LINE IN: 3.5mm audio
interface
2 x Built-in microphone
Communication
Interface
1 x RS485: 3pin phoenix port;
Max Distance: 1200m;
Protocol: VISCA/Pelco-D
/Pelco-P
Power Interface
JEITA type (DC IN 12V)
RESET Key
Pinhole RESET
General Specifications
Input Voltage
DC 12V
Input Current
3.0A
Battery
9450mAh
Operating
Temperature
0°C~40°C
Storage
Temperature
-40°C~60°C
Power
Consumption
36W (max.)
Dimension
143mm x 189.3mm x 201.6mm
Net Weight
About 1.9Kg
Product specifications are subject to change
without notice.
4.3 Interfaces and Keys
No.
Name
1
RESET Key
2
DC 12V Interface
3
RS485 Interface
4
HDMI Interface
5
USB Interface
6
LINE IN Interface
7
LAN Interface
8
Power Key
RESET DC 12V HDMI USB LINE I AN
1 2 3 4 5 6 7 8
