3
4.2 Specifications
Camera
Video System
4KP30, 4KP25, 1080P30,
1080P25
Sensor
1/1.8-inch, CMOS,
Effective Pixel: 8.42M
Scanning Mode
Progressive
Lens
20x, f=6.25mm~125mm,
F1.58~F3.95
Digital Zoom
16x
Minimum
Illumination
0.5 Lux @ (F1.8, AGC ON)
Shutter
1/30s~1/10000s
White Balance
Auto, Indoor, Outdoor,
One Push, Manual, VAR
Backlight
Compensation
Support
Digital Noise
Reduction
2D & 3D Digital Noise
Reduction
SNR
≥55dB
Horizontal FOV
60°~3.5°
Vertical FOV
35.7°~2.0°
Pan Angle
±170°
Tilt Angle
-30°~+90°
Pan Speed
2.7°/s~35.7°/s
Tilt Speed
2.7°/s~31.5°/s
Image Flip
Support
Auto ICR
Support (Auto mode of IR Cut
filter Removal)
Day/Night Mode
Support
Image Freeze
Support
Preset Position
255
Preset Accuracy
0.1°
USB Features
Operate System
Windows 7/8/10/11,
Mac OS X, Linux, Android
Color System/
Compression
YUY2/MJPEG/H.264
Video Format
YUY2 (ISOC): 1440P30 (max.)
MJPEG: 2160P30 (max.)
H.264 AVC: 2160P30 (max.)
USB Audio
UAC 1.0
USB Protocol
UVC 1.1
UVC PTZ Control
Support
Network Features
Video
Compression
H.264/H.265/MJPEG
Video Stream
First Stream, Second Stream
First Stream
Resolution
3840x2160, 1920x1080,
1280x720, 1024x576, 960x540,
640x480, 640x360
Second Stream
Resolution
640x360, 480x272, 320x240,
320x180
Video Bit Rate
32Kbps~20480Kbps
Bit Rate Control
CBR, VBR
Frame Rate
50Hz: 1fps~25fps,
60Hz: 1fps~30fps
Audio Type
AAC
Audio Bit Rate
96K, 128K, 256K
Network
Protocol
TCP/IP, HTTP, RTSP, RTMP(S),
ONVIF, DHCP, Multicast,
NDI-HX, etc…
Wireless Features
Work Frequency
5.15GHz~5.35GHz,
5.425GHz~5.725GHz,
5.745GHz~5.850GHz
Transmission
Power
27dBm
Antenna Mode
2*2MIMO, Beamforming
Channel
Bandwidth
20/40MHz
Modulation
Mode
OFDM
Data Rate
300Mbps (max.)
Network Mode
Point to Point, Point to
Multipoint
Penetration
1~2 walls
Transmission
Distance
200M
Protocol
802.11a/n
