Troubleshooting

Operating Instructions D867 e-con - 00.0 - 06/2023 231

3223 Information No loop (right) Skip stitch monitor

• The sensor of the skip stitch monitor

detected during the sewing process that

the loop of the needle thread was not

taken up, resulting in a “skip stitch”.

3224 Information Bobbin Rotation Monitor • The bobbin is not rotating

• Check the bobbin, advance the initial

thread

3225 Information SSD sensor is soiled • Use compressed air or a soft cotton cloth

to clean the sensor

3226 Information No loop (left) Skip stitch monitor

• The sensor of the skip stitch monitor

detected during the sewing process that

the loop of the needle thread was not

taken up, resulting in a “skip stitch”.

3227 Information Bobbin Rotation (left) Bobbin Rotation Monitor

• The sensor of the bobbin rotation monitor

detected during the sewing process that

no hook thread was consumed and that

the seam was apparently not created

properly.

3228 Information Clean Loop Control sensor

(left)

Sensors soiled

• The optical sensors for the skip stitch

monitor, the bobbin rotation monitor and

the remaining thread monitor are soiled

and deliver no reliable signal.

Please clean dirt off the sensors using

compressed air or a soft brush.

3354 Information Failure in thread trimmer

process

• Perform software update

3383 Information Failure in the motor

referencing process

• Check motor

• Perform software update

4201 Warning Failure SD-Card • Insert SD card

• Replace the control

4430 Warning Commander connection lost • Switch off the control

• Check control panel connection

Code Type Possible cause Corrective
