Setup
206 Operating Instructions D867 e-con - 00.0 - 06/2023
7.17 Pneumatic connection (optional)
The pneumatic system of the machine and of the additional
equipment must be supplied with dry and oil-free compressed air.
The supply pressure must lie between 8 and 10 bar.
Information
The pneumatic connection package is available under part
number 0797 003031. It consists of:
• System connection hose (length 5 m, diameter 9 mm)
• Hose connectors and hose clamps
• Coupling socket and coupling plug
NOTICE
Property damage from oily compressed air!
Oil particles in the compressed air can cause malfunctions
of the machine and soil the sewing material.
Ensure that no oil particles enter the compressed air supply.
NOTICE
Property damage from incorrect adjustment!
Incorrect system pressure can result in damage to the
machine.
Ensure that the machine is only used when the system
pressure is set correctly.
