Programming Commander DELTA

82 Instructions for use 550-D869-100 e-con - 00.0 - 01/2025

5.7.3 Setting cross-segment parameters

There are various options for setting the cross-segment parame-

ters. The following table lists all possible options.

Settings that are more complex and therefore require further

explanation are described in more detail after the table.

Button Parameter Settings

Additional values (+)

Additional value stitch length (+)

The 2

nd

value for the stitch length can be

switched on using a button on the push

button panel or the button on the control

panel.

Value range

00.0 - 12.0

(depending on sewing equipment

and subclass)

Additional value sewing foot stroke (+)

The 2

nd

value for the sewing foot stroke

can be switched on using a button on

the push button panel, the knee button or

the button on the control panel.

Value range

00.5–09.0 [mm]

Additional value needle thread tension (+)

The 2

nd

value for the needle thread ten-

sion can be switched on using a button

on the push button panel or the button on

the control panel.

Value range

01 - 99

Gap (2

nd

value)

The 2

nd

value for the gap of motor driven

(lateral) edge guide to the needle (consid-

ering the defined safety clearance to the

sewing feet).

Value range

1.0 - 45.0

(depends on the sewing

equipment)

Main Parameter

Bobbin monitor mode (see  p. 85)

Point position

The distance of the needle from the mate-

rial can be adjusted to allow precise posi-

tioning of the sewing material when

starting sewing.

The value entered corresponds to the

degree number on the handwheel.

Value range

000–359 [°]
