Operation

Instructions for use 550-D869-100 e-con - 00.0 - 01/2025 45

4.14 Sewing

Fig. 23: Sewing

The pedal starts and controls the sewing process.

WARNING

Risk of injury from the needle if sewing is

started unintentionally!

Puncture possible.

Do not press the pedal when your fingers are in

the area of the needle tip.

(1) - Position +1

(2) - Position 0

(3) - Position -1

(4) - Position -2

Status Processes

Before starting sewing

Initial situation • Pedal in rest position (position 0)

Machine is at a standstill.

The needle is up, and the sewing feet are down.

Positioning

the sewing

material

• Press the pedal halfway back (position -1).

The sewing feet are lifted.

• Correct the position of the sewing material.

• Release the pedal.

Sewing feet are lowered onto the sewing material.

①

②

③

④
