Disconnect the plug from the
power source before making
any assembly, adjustments or changing
accessories. Such preventive safety measures
reduce the risk of starting the tool accidentally.
For all work or when
changing accessories always
wear protective gloves. Such preventive safety
measures reduce the risk of injury from sharp edges
of the accessories. Application tools can become
very hot while working. Danger of burns!
INSTALLING ACCESSORIES WITH
EASY-LOCK ACCESSORY CHANGE
Only use Dremel accessories
rated 21000 OPM or greater.
Using accessories not designed for this power tool
may result in serious personal injury and property
damage.
The Dremel Multi-Max MM35 was designed with an
integrated accessory change mechanism. The Easy-
Lock accessory interface allows you to install and
remove accessories without the need of a wrench or
hex key.
1. To install an accessory using the Easy-Lock feature,
first loosen the clamping knob by twisting it in a
counter-clockwise direction (Fig. 2).
2. Press the clamping knob so that the clamping
flange extends enough to fit a blade in between the
clamping flange and the interface. You may need to
loosen the clamping knob more to allow adequate
room for the accessory. (Fig. 3)
3. Place the accessory onto the interface, making
sure the accessory engages all pins on the
interface and the accessory is flush against the
accessory holder (Fig. 4).
4. Release pressure on the clamping knob. The spring
action of the mechanism will hold the blade in
place while you secure it (Fig. 5).
5. Tighten the clamping knob by twisting in a clockwise
direction (Fig. 2). Make sure to tighten fully, until
you can’t twist the clamping knob (without it being
uncomfortable).
-9-
Assembly
FIG. 3
FIG. 2
Clamping
Knob
Pins
Flange
Accessory
FIG. 5
FIG. 4
