Shower Enclosure Plan

Unidoor Plus models

with Glass-to-Wall hinges

UNIDOOR PLUS

5UNIDOOR PLUS Style L Shower Enclosure Panel Manual Ver 2 012020

Outside surface

of the door glass

G = (30”)

A= (30-7/16”)

Outside surface of the

return panel u-channel

Return Panel

A = (30-7/16”)

G =

(30”)

Return Panel U-channel =

Glass Width + 3/16”

Bottom U-Channel

cut size

Finished wall surface

Outside surface

of the door glass

Finished wall surface

door

Return panel

Return

Panel

A

Door

Return Panel

Door

A

G

Door

(30”)

STYLE L

Outside surface

of the return

panel u-channel

Outside surface

of the return

panel glass

Outside surface

of the return

panel glass

Style L

right-hand return panel installation shown

NOTE

Measure at the bottom

and draw a plumb line up

from the threshold
