Parts Needed

20

PRISM PLUS Shower Enclosure Manual Ver 2 012020

Fig 13

DO NOT install the Handle onto the glass until instructed. DO NOT lift the glass using

the Handle. This could result in damage to the glass and /or serious personal injury.

Always use an assistant or a professional grade glass suction cup when handling heavy

glass.

Return Panel Glass (#01)

23-15/16”

(Left-hand swing installation shown)

Before installing the Door glass (#02), attach the 135° Strike Vinyl (#14) to the edge of

the Return Panel Glass (#01) to protect the edge of the glass during installation of the

Door Glass (#02).

TIP

Allow the silicone in the U-Channel holding the Hinge Panel Glass (#02) to set before

hanging the door glass. Leave the shims in place under the door glass while the silicone

cures, especially if there is an out-of-plumb wall condition.

!

NOTE

Lorem ipsum

13
