Tools Needed
PRISM PLUS Shower Enclosure Manual Ver 2 012020
19
© 2020 DreamLine® All Rights Reserved
NOTE
1 2 3* 4*
5
(Left-hand L-Bar™ Support Bracket shown)
Max 3/16” (4mm)
Max 3/16” (4mm)
* To adjust the angle of the L-Bar™: Loosen the M5 x 14.5 screws, rotate the
appropriate set screw (See Fig 12.3 and 12.4) to adjust the angle of the L-Bar™
(up to 3/16” (4mm)) in the desired direction. Hand tighten the M5 x 14.5
screws after adjustment is complete and replace the decorative cover.
12
