13
DRAWMER 1971 OPERATOR’S MANUAL
IF A FAULT DEVELOPS
For warranty service please call Drawmer Electronics Ltd. or
their nearest authorised service facility, giving full details of the
diculty.
A list of all main dealers can be found on the Drawmer webpages.
On receipt of this information, service or shipping instructions
will be forwarded to you.
No equipment should be returned under the warranty without
prior consent from Drawmer or their authorised representative.
For service claims under the warranty agreement a service
Returns Authorisation (RA) number will be issued.
Write this RA number in large letters in a prominent position
on the shipping box. Enclose your name, address, telephone
number, copy of the original sales invoice and a detailed
description of the problem.
Authorised returns should be prepaid and must be insured.
All Drawmer products are packaged in specially designed
containers for protection. If the unit is to be returned, the original
container must be used. If this container is not available, then
the equipment should be packaged in substantial shock-proof
material, capable of withstanding the handling for the transit.
CONTACTING DRAWMER
Drawmer Electronics Ltd., will be pleased to answer all
application questions to enhance your usage of this equipment.
Please address correspondence to:
Drawmer (Technical Help line)
Coleman Street
Parkgate
Rotherham
S62 6EL
UK
Alternatively contact us by E-mail on :
tech@drawmer.com
Further information on all Drawmer dealers, Authorised service
departments and other contact information can be obtained from
our web pages on:
http://www.drawmer.com
GENERAL INFORMATION
CHAPTER 3
INPUT
Input Impedance 20k Ohms or greater
Maximum Input Level +21dBu
OUTPUT
Output Impedance <100 Ohms
Maximum Output Level +21dBu into 10k Ohms Load
FREQUENCY RESPONSE
20Hz to 20kHz +/-0.5dB
CROSSTALK < -90dB @ 1kHz
% DISTORTION (THD & NOISE) @ 1kHz
0dB 0.003%
1971 DUAL PARAMETRIC EQUALISER
DATA SPECIFICATION
POWER REQUIREMENTS
230Volt or 115V at 50-60hZ, 15VA
FUSE RATING
T250mA for 230Volt,
T500mA for 115Volt
Conforming to IEC 127-2
FUSE TYPE
20mm x 5mm, Class 3 Timed-Blo, 250Volt working
CASE SIZE
482mm (W) x 88mm (H) x 270mm (D)
WEIGHT 4.3Kgs
