24338
EN
Original Instructions
Version 3 - June 2025
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. Please visit
drapertools.com/manuals for the latest version.
1. Intended Use
Designed to clean, dry and regulate compressed air.
Any other application will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
2. Specication
Stock No. 24338
Part No. ALFR2
Inlet/Outlet thread ½” BSP
Max. inlet pressure 10bar (145psi)
Max. temperature 60°C
Filtration element 40 microns
3. HealthandSafetyInformation
Important: Read all Health and Safety instructions before attempting to operate,
maintain or repair this product. Failure to follow these instructions may result in
injury or damage to the user or the product.
3.1 GeneralSafetyInstructionsForCompressedAir
Following Safety instructions should be strictly followed. Failure to do so may
result in accidents, equipment malfunctioning, serious personal Injury and / or
loss of life.
Compressed air is a source of considerable energy. When handling products
dealing with compressed air, the following precautions must be taken to
prevent accidents.
1. Ensure that compressed air is not blocked or in contact with any part of
your body.
2. Before connecting any pneumatic equipment to the compressed air supply,
all mounted ttings, piping assemblies and electrical connections should be
checked for security. All plastic plugs in the equipment used for protection
during shipping should be removed.
3. No piping alterations, removal of ttings, repairing of equipment etc. should
be attempted with air supplies connected. Air and electrical supplies must be
disconnected before beginning any adjustment, maintenance or dismantling
of equipment.
4. The maximum allowable operating pressures, temperature, ows etc. must be
strictly observed. Failure to do so might result in catastrophic failure of
equipment, and result in serious personal injury and / or death. Refer to
individual catalogues for this information, and any other operating or
application limitations.
3.2 CompressedAirSafetyforPneumaticEquipment
WARNING!
1. Compatibility of pneumatic equipment
Ensuring the compatibility of the procured FRL equipment is the responsibility
of the person who designs the Pneumatic system and/ or System
specications. This should be based on specications or after analysis and /
or tests to meet specic requirements.
2. Repair & Maintenance
Assembly, handling, or repair of pneumatic systems should be performed by
only trained and experienced operators.
3. Safety First
Do not service machinery / equipment or attempt to remove any component
until safety Is conrmed.
• Inspection and maintenance of machinery / equipment should only be
performed after conrmation that both compressed air and electrical supply
have been positively disconnected and all residual compressed air in the
system has been completely exhausted to the atmosphere.
Delta International
Delta International BV
Oude Graaf 8
6002 NL
Weert
Netherlands
Draper Tools
Draper Tools Limited
Hursley Road, Chandler’s Ford
Eastleigh, Hampshire, SO53 1YF UK
Website: drapertools.com
Email: sales@drapertools.com
Product Helpline: +44 (0) 23 8049 4344
Telephone Sales Desk: +44 (0) 23 8049 4333
General Enquiries: +44 (0) 23 8026 6355
© Published by Draper Tools Limited
F I LT E R /
REGULATOR
UNIT
