3. Product Introduction
EN
3.1 Scope
This product is designed as a high-level stand to safely
give support under car components such as; exhausts,
sub frames, axles, dierentials & prop-shafts. Suitable for
use with large and heavy goods vehicles, trucks and
buses. The stand is supplied with 3 interchangeable
saddles and retractable castors for easy movement.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts
no responsibility for improper use of this product.
This product is intended for frequent trade use, with the
quality and features to meet and exceed expectations of
the most demanding user.
Read this manual in full before attempting to assemble,
operate or maintain the product, and retain it for later use.
– 4 –
Stock No. 20118
Part No. AS-12
Capacity per stand: 12Tonne
Minimum Height: 1300mm
Maximum Height: 1905mm
Saddle Height range: 605mm
Shallow Head Saddle: 130 X 100mm
Deep Head Saddle: 150 X 120mm
V-Shaped Saddle: 180 X 75mm
Base Diameter: 50 x 50mm
Net Weight: 78kg
3.2 Specication
Read the instruction manual
Warning!
Wear face mask and safety glasses
4. Explanation of Symbols
EN
Wear protective footwear
Keep out of the reach of children
