– 4 –
3. Product Introduction
3.1 Intended Use
This sprayer is designed to be mounted to an all-terrain
vehicle (ATV) using the straps supplied to secure. The
26176 and 26180 sprayers are supplied with two lances:
one to attach to the tank bracket for broadcast spraying
and the other for hand operation using the trigger.
Ideal for spraying fertiliser, weed killer, de-icer and
ethylene glycol products.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts
no responsibility for improper use of this product.
Read this manual in full before attempting to assemble,
operate or maintain the product, and retain it for later
use.
3.2 Specication
• Before using any chemicals, check that the chemical is compatible with all the component materials listed above.
Stock No.: 26175 26176 26180
Part No.: ATVSS37L ATVSS60L ATVSS98L
Power supply: 12V DC battery 12V DC battery 12V DC battery
Pump fuse: 5A 15A 15A
Tank size: 37L 60L 98L
Max ow rate: 3.8LPM 7.5LPM 7.5LPM
Max pressure: 40PSI (2.76bars) 70PSI (4.8bars) 70PSI (4.8bars)
Hose length (approx.) 4.75M 4.75M 4.75M
Spray pattern: Stream/Cone Stream/Cone Stream/Cone
Broadcast spray (height): N/A 5.8M 5.8M
Dimensions (L×W×H): 710 × 300 × 270mm 840 × 345 × 375mm 840 × 350 × 520mm
Net Weight:
Empty: 4kg 8.3kg 9.9kg
Full: 41kg 68.3kg 108kg
Component Materials *
Tank: High density polyethylene (HDPE)
Suction tube: Polypropylene, PVC, Stainless Steel
Hose: PVC
Pump: Polypropylene, Viton®, Santoprene®, Stainless Steel
Valves: PVC, Buna-N
Gun and nozzle: Nylon, Polyacetal, Aluminium
