5. Identication and Unpacking
EN
– 7 –
(1) 2 X AC power outlet
(2) ON/OFF switch
(3) USB DC output
(4) Power indicator
(5) Low battery indicator
(6) Red positive (+) terminal cap
(7) Black negative (-) terminal cap
(8) Earth point connection
(9) 4 X Anchor points (on both sides)
(10) Battery black negative (-) terminal connection lead
(10a) fork spade wire connector (negative)
(11) Battery red positive (+) terminal connection lead
(11a) fork spade wire connector (positive)
Carefully remove the product from the packaging and
examine it for any signs of damage that may have
occurred during shipment. If any part is damaged or
missing, do not attempt to use the product. Please
contact the Draper Helpline; contact details can be
found at the back of this manual.
Please visit drapertools.com for our full range of accessories and consumables.
(10a)
(11a)
(8)
(5)
(4)
(11)(9)
(10)
(9)
(6)
(7)
(3)
(2)
(1)
