Please visit drapertools.com for our full range of accessories and consumables.
6.3 Packaging
Keep the product packaging for the duration of the
warranty period in case the product needs to be returned
for repair.
WARNING! Keep packaging materials out of reach of
children. Dispose of packaging correctly and
responsibly and in accordance with local regulations.
(A) 1 x Support column assembly
(B) 1 x Rear crossbar
(C) 1 x Front crossbar
(D) 1 x Central arm
(E) 2 x Front castors
(F) 2 x Rear wheels
(G) 1 x Mounting plate
(H) 1 x Mounting plate handle
(I) 4 x Mounting arms
(J) 3 x M12 x 80mm hex bolts
(K) 4 x M12 x 40mm hex bolts
(L) 2 x M14 washers
(M) 6 x M12 washers
(N) 9 x M12 spring washers
(O) 8 x M12 nuts
(P) 1 x Locking pin
(Q) 2 x Split pins
6.2 What’s in The Box?
Carefully remove the product from the packaging and
examine it for any signs of damage that may have
occurred during shipment.
Before assembling the product, lay the contents out and
check them against the parts listed below. If any part is
damaged or missing, do not attempt to use the product.
Please contact the Draper Helpline; contact details can
be found at the back of this manual.
(A)
(B)
(H)
(P)
(C)
(D)
(N, O)
(J)
(J, N)
(M, N, O )
(G)
(K, M)
(I)
(N, O)
(E)
(F, L, Q)
6. Identication and Unpacking
– 8 –
EN
