It is possible that these manual still contains typographical errors
or printing errors.The information in this manual will be checked
regularly and corrections will be made in the next version. We accept
no liability for errors of a technical or printing nature and their
consequences.
GENERAL
Material Polycarbonate
Mounting type
Surface. Mounting brackets with
two different angles included.
Tripod thread DIN 4503-1 / ISO
1222 also supported.
Dimensions
33 x 70 x 70 mm (L x W x H)
1.30 x 2.75 x 2.75 in (L x W x H)
Power supply
48 V DC. Power supply unit not
included.
Power
consumption
max. 1 W
Operating
conditions
-25 to +55°C / -13 to 131°F
Humidity 10 to 85 % RH
(non-condensing)
Protection class IP65
Approvals CE, FCC, IC, RoHS, REACH, WEEE
Scope of delivery
1x 4D Security Radar Motion
Sensor A8008
1x Installation manual
2x Connection cable
1x Wall mount adapter
1x Small Parts
Connectors
• 1x Bistable latching relay, max.
1 - 24 V DC/AC, 1 A, e.g. to trigger
an an alarm or turn on a light
• 1x Bistable latching relay, max.
1 - 48 V DC/AC, 1 A, e.g. to trigger
an an alarm or turn on a light
• 5 - 57 V DC input (+, -)
Controls
• LED on/off
• Motion detection direction
(Off, Coming, Leaving, Coming/
Leaving)
• LUX intensity
• Trigger duration time of Relay 1,
up to 15 min
• Sensitivity / Distance of the
Radar, 1 to 10m /
3.3 ft to 33 ft
LED Motion Detection
Weight
A8008: 67,5 g
Wall mount adapter: 10 g
EAN 4251489602148
Warranty see www.doorbird.com/warranty
Garantie siehe www.doorbird.com/warranty
MOTION SENSOR
Type Active
Detection angle 54° (H), 70° (V)
Range
1 - 10 m (3.3 - 32.9 ft), depends
on environment, configurable via
rotary control.
Technology
4D, Based on multiple integrated
sensors and algorithms, e.g.
Radio Frequency Energy (RFE)
Configuration
Via controls, e.g.
• Range (1 - 10 m / 3.3 - 32.9 ft)
• Movement direction (coming,
leaving, both)
• Day/night switchover
INTEGRATED WIRELESS MODULES
Sensor 24 GHz, can be disabled
OPTIONAL ACCESSORIES
Sold separately
Power supply unit (main adaptor)
with 4 country-specific outlet
adaptors
TECHNICAL DATA
