NU 3600 Installation
EN
13
For connection, see chapter “Connect battery monitor” on page 14.
7.3 Switching signal 12V
A 12V potential-free signal at Signal OUT (3) can be activated when there is mains from grid (AC1-IN,
1). This signal can be used to indicate the mains input for example by lighting an external lamp. For
connection, see chapter “Connect switching signal 12 V” on page 14.
The signal can be delayed by 2s, 2min, 10min or not at all, by setting the jumper position. The
default setting is 2min delay.
7.4 Combining both 12V signals
The two 12V signals (3, 4) can also be connected in series. That means that the switch output
(AC-OUT2, 5) will have power either only when there is mains from grid (AC1-IN, 1) or from inverter
(AC2-IN, 7). With a delay time, it can for example mean that an air conditioner starts 10 minutes after
mains voltage has been connected (fig. 5, page 7).
8 Installation
8.1 Choosing a location
Install the device in a clean area inside the RV where it is protected against vibrations, explosive
materials, moisture, heat, and pollution.
8.2 Installation procedure
!
!
!
➤ Connect the cable according to the wiring diagram (fig. 6, page 8).
– Connect the cables through the existing rubber sleeves, protected outside against tensile
loads and vibration. The diameters of the cables used must correspond to the diameter of
the rubber sleeves in order to comply with the IP rating.
WARNING! Electrocution hazard
The installation may only be carried out by a qualified electrician.
WARNING! Electrocution hazard
Before any work on the 230 VAC wiring is performed, switch off all dangerous voltage.
Ensure that no accidental switching on or plugging in of mains voltage is possible.
WARNING! Electrocution hazard
Never put cables for 12VDC voltage and 230VAC voltage in the same cable duct.
