Technical description NU 3600
EN
12
Dometic reserves the right to change product appearance and product specifications.
7 Technical description
If a mains voltage and voltage generated by the inverter (RV house battery) are both connected to
the device, the use of the mains voltage has priority (fig. 1, page 3). If only voltage generated by
the inverter is available, the power supply from the battery is used to provide power output from
AC-OUT2 (fig. 2, page 4). This ensures that the limited power of the battery is only used when nec-
essary.
The device has seven connections for input and output, explained below.
A
7.1 Output to permanent AC loads
Electrical devices such as refrigerators and battery chargers can be connected to only receive
power output from the mains voltage, via the AC1-OUT output. When no mains voltage input is avail-
able, there is no power supply for AC1-OUT (fig. 1 and fig. 2, page 4).
7.2 Switch output
The switch output AC-OUT2 (5) is controlled by a 12V input signal (4). When switched on, the
AC-OUT2 (5) receives power from either the inverter AC2-IN (7) or mains from grid (AC1-IN, 1 ), just like
AC-OUT (6). To enable this function, connect the input switch signal to an external device with a
switch function, for example a battery monitor. See chapter “Accessories” on page 11 for recom-
mended battery monitors that include additional functions such as turning the switch on or off
depending on battery level (fig. 4, page 6).
Item in
fig. 3,
page 5
Wiring dia-
gram
Description
1 AC1-IN 230 Vw External mains input from grid
2 AC1-OUT 230 Vw output to permanent AC loads
(Only output from input mains from grid)
3 Signal OUT 12V g output switch signal
4 ON OUT2 12V g input switch signal for AC-OUT2
5 AC-OUT2 230 Vw switch output
6 AC-OUT 230 Vw cabin socket output
7 AC2 -IN 230 Vw inverter input
NOTICE!
Max. load is 3600VA and 16A.
