4.7. Connecting Multiple Devices
To create a setup with multiple devices, you need to connect the devices vertically and horizontally.
4.7.1. Vertical Installation
By the vertical installation, 2 LED screens are connected below one another.
To connect vertically 2 LED screens, follow the steps below:
01) Put a 2nd screen below the 1st screen and let the magnetic top of the 2nd screen snap to the bottom of01)
the 1st screen, as shown in Fig. 38.
02)
Turn lever (A) of the left locking mechanism (06) counterclockwise.
02)
03)
Push the left spring-loaded fast-lock (B) of the left locking mechanism (06) of the 2nd LED screen upwards
03)
and turn it by 90° clockwise or counterclockwise, as shown in Fig. 39 and 40.
Figure 38 Figure 39
Figure 40
22
