Digi-Pas
®
© 2023 Digipas Technologies Inc. All Rights Reserved.
www.digipas.com
Page 35
DWL-5x000XY DATA SHEET
Byte[0] Byte[1] Byte[2] Byte[3] Byte[4] Byte[5] Byte[6] Byte[7] Byte[8] Byte[9] Byte[10] Byte[11]
0x06 0x01 0x01 0xAA 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00
Byte[n] Byte[0] Byte[1] Byte[2] Byte[3] Byte[4]..[11]
Byte description Source Destination Mode Data Data
Command 0x06 0x01 0x01 0xAA 0x00
Command description Computer Sensor Single Axis Mode Dummy Dummy
6.5. Commands for Mode Selection
Following shows the command of mode selection:
Command Descriptions
0x01 Single Axis Mode
0x02 Dual Axis Mode
0x03 Vibro Mode
0x0B Calibration Mode
0x07 Alternate Zero in Single Axis Mode
0x0A Alternate Zero in Dual Axis Mode
0x08 Location Mode
The detailed information of each command is explained in Section 6.5.1 to 6.5.7. Please note that
all the angle values and CRC16 values are for illustration purposes only.
6.5.1. Single Axis Mode
To set the tilt sensor module into Single Axis Mode:
<< (To sensor) : 0x06, 0x01, 0x01, 0xAA, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00
Byte [n] Command Descriptions
Byte [0] 0x06 From Computer
Byte [1] 0x01 To Sensor
Byte [2] 0x01 Single Axis Mode
Byte [3] 0xAA
Dummy
Byte [4]~ [11] 0x00 Not Applicable
Data received from tilt sensor module:
>> (From sensor) : 0x61, 0x11, 0x01, 0x12, 0xA8, 0x80, 0x01, 0x13, 0x88, 0xAA, 0x16, 0x46
