5.9 Generator Port Use Setup Menu
- �� -
Mode
OFF
ON
Generator Input
SmartLoad Output
Micro Inv Input
On Grid always on
GEN connect to Grid input
AC couple on grid side
AC couple on load side
Ml export to Grid cutoff
GEN PORT USE
55.00Hz
154.0V
151.0V
Rated Power
AC Couple Frz High
8000W
PORT
Set1
Mode
OFF
ON
Generator Input
SmartLoad Output
Micro Inv Input
On Grid always on
GEN connect to Grid input
Ml export to Grid cutoff
GEN PORT USE
55.00Hz
100%
95%
Rated Power
AC Couple Frz High
8000W
PORT
Set1
Mode
OFF
ON
Generator Input
SmartLoad Output
Micro Inv Input
On Grid always on
GEN connect to Grid input
Ml export to Grid cutoff
GEN PORT USE
55.00Hz
90%
100%
Rated Power
AC Couple Frz High
8000W
PORT
Set1
AC couple on grid side
AC couple on load side
AC couple on grid side
AC couple on load side
GEN port is a multifunctional port, but you can only choose one
of the following three functions at a time.
Generator input rated power: allowed Max. power from diesel
generator.
GEN connect to grid input: connect the diesel generator to the
grid input port.
Smart Load Output: Use the GEN port as an AC output port, and
the load connected to this port can be controlled on/off by the
hybrid inverter.
e.g. ON: 100%, OFF: 95%: When the battery bank SOC reaches
100%, Smart Load Port will switch on automatically and power
the load connected. When the battery bank SOC < 95% , the
Smart Load Port will switch off automatically.
Smart Load OFF Batt
• Battery SOC or voltage at which the Smart load will switch off.
Smart Load ON Batt
• Battery SOC or voltage at which the Smart load will switch on.
On Grid always on: When "on Grid always on" is checked, the
smart load port will always keep switching on if hybrid inverter is
operating in on-grid mode.
Micro Inv Input: Use the GEN port as an AC couple input port,
which can be connected with micro-inverter or other Grid-Tied
inverter.
＊Micro Inv Input ON: When the hybrid inverter operates in
off-grid mode and the SOC or voltage of battery drops to this set
value, the relays on GEN port of hybrid inverter will turn to
normally closed(ON), then the Grid-Tied inverter will generate
solar power and feed into hybrid inverter. When the hybrid inverter
operates in on-grid mode, this parameter will be invalid, the relays
on GEN port of hybrid inverter will always be normally colsed(ON),
Grid-Tied inverter can operate normally.
AC Couple Frz High: If choosing"Micro Inv input", as the battery
SOC reaches gradually setting value (OFF), during the process, the
microinverter output power will decrease linear. When the battery
SOC equals to the setting value (OFF), the system frequency will
become the setting value (AC couple Frz high) and the Microinvert-
er will stop working.
Ml export to Grid cutoff: Stop exporting power produced by the
microinverter or Grid-Tied inverter to the grid.
AC couple on Load side: Connect one or several on-grid inverters
on the Load port side of this hybrid inverter.
AC couple on Grid side: Connect one or several on-grid inverters
on the Grid port side of this hybrid inverter.
＊Note: Micro Inv Input OFF and On is valid for some certain FW
version only.
