Lithium Mode
Shutdown
Low Batt
Restart
40%
20%
10%
00
Battery Setting
Set3
Batt
Float V
Shutdown
Low Batt
Restart
500V
470V
450V
536V
Battery Setting
Set3
Batt
Click the generator icon on the main screen, you can enter the
'Generator' detail page. The information contained on this
page is as follows:
(1) How much power is using from generator;
(2) How much energy has used from generator in today or in
total;
(3) The output voltage and power on each phase of generator.
When the "Lithium" mode is selected, the content on the "Batt Set 3"
page is shown in the figure on the left.
Lithium Mode: This is the BMS communication protocol code which
can be confirmed on the "Deye Approved Battery list" based on the
battery model you are using.
Shutdown：Be valid in Off-grid mode, battery can discharge to this
SOC, then the DC/AC inverter module of this inverter will be shut
down and the solar power can only be used to charge the battery.
Low Batt ：Be valid in On-grid mode, when the 'Grid charge' has
been checked and the set target battery SOC on 'Time of Use' page
isn't less than the "Low Batt" value, the battery SOC will remain
above the value of "Low Batt" .
Restart ：Be valid in Off-grid mode, after the DC/AC inverter module
of this inverter is shut down, the PV power can only be used to
charge the battery. After the battery SOC has resumed to this
"Restart" value, the DC/AC inverter module will restart to output AC
power.
When the "Use Batt V" mode is selected, the content on the "Batt
Set 3" page is shown in the figure on the left.
Float voltage: Battery full charge voltage.
Shutdown : Be valid in Off-grid mode, battery can discharge to
this voltage, then the DC/AC inverter module of this inverter will be
shut down and the solar power can only be used to charge the
battery.
Low Batt ：Be valid in On-grid mode, when the 'Grid charge' has
been checked and the set target battery voltage on 'Time of Use'
page isn't less than the "Low Batt" value, the battery voltage will
remain above the value of "Low Batt" .
Restart ：Be valid in Off-grid mode, after the DC/AC inverter
module of this inverter is shut down, the PV power can only be
used to charge the battery. After the battery voltage has resumed
to this "Restart" value, the DC/AC inverter module will restart to
output AC power.
Power: 6000W Today=10 KWH
Total =10 KWH
Generator
V_L1: 230V
V_L2: 230V
V_L3: 230V
P_L1: 2KW
P_L2: 2KW
P_L3: 2KW
Recommended battery settings
Battery Type Absorption Stage Float Stage
Equalization Voltage
(every 30 days 3hr )
Lithium Follow its BMS voltage parameters
When the "GEN signal" is active, the generator icon
will appear on the main screen of inverter LCD
display.
01/19/2024 01:23:02 PM Fri
0.00
KW
0.14
KW
0.00
KW
KW
0.00
KW
0 50
0 50
0 50
0 50
ON
Signal
on
0.00
Off grid
25%
