Je bekijkt pagina 27 van 59
24
voltage control box
⑧
HV light indicator
High-voltage hazard indicator (yellow)
Front
⑨
ALRM light
indicator
Battery system fault alarm indicator (red)
Front
⑩
PCS-
Connection position of PCS negative pole (black)
Front
⑪
PCS+
Connection position of PCS positive pole (orange)
Front
⑫
Grounding wire
identification
Connection to the battery rack and the ground point
Front
⑬
OUT COM
Connection position with next BOS-G-PDU-2
communication output
Rear
⑭
IN COM
Connection position with previous BOS-G-PDU-2
communication input
Rear
⑮
PCS COM
PCS COM battery communication terminal: (RJ45
port) follow the CAN Protocol (default baud rate:
500bps) and RS485 Protocol (default baud
rate:9.6bps), used to output battery information to
the inverter.
Rear
⑯
POWER
Connection position of external 12VDC power
supply
Rear
