18
Main Connections
Using the VIVO SX7 with Your Computer
If you use a USB cable (commercially available) to connect the USB
COMPUTER port on the VIVO SX7’s rear panel to your computer’s
USB connector, you can record and play audio or MIDI data by your MIDI
software (DAW software).
NOTE
To use the USB audio streaming you need of a computer
equiped with MAC OSX or LINUX, an iPad or iPhone.
USB MIDI + AUDIO Streaming
1. Use a AgB-type USB cable (sold separately) to connect
the VIVO SX7 to your computer.
NOTE
• Switch on the VIVO SX7 before you start up the DAW software
on your computer.
• Before to connect any other equipment, move the [VOLUME]
knob counterclockwise to minimize the volume.
Now, the same sound of the VIVO SX7's audio OUTPUT (unbalanced
or balanced) can be recorded into your computer and the sound
from your computer can be played from audio system conencted to
the VIVO SX7's audio OUTPUT jacks.
USB Audio Feature
Thanks to the USB audio you can record the audio of the VIVO SX7
directly without using any internal digital analogue converter. This greatly
increases audio quality and noise immunity.
Audio Flow
USB
Sound Generator
digital audio
analog audio signal
D
A
C
balancer
L
R
BALANCED OUTPUTOUTPUT
The VIVO SX7’s audio format:
Sampling rate 48 Khz
Bit depth 24
Number of channel 3
NOTE
To use the USB audio streaming you need of a computer
equiped with MAC OSX or LINUX, an iPad or iPhone.
Adjusting the USB Audio
Use this function if you need to adjust the audio output and input levels
via USB.
1. Press [MENU/EXIT] button and select USB AUDIO.
2. Use the [] [] buttons to select the parameter you want
to edit.
3. Use the [DATA ENTRY] knob to choose the desiderate
audio level.
